Error Code Identification - Steam Single

Error Code Identification - Steam Single



Steam Single Error Code Identification


  1. 015 - Reservoir Low Water Level
    1. Machine software detected a condition of low water level  in the reservoir.
  2. 016 - Brew Actuator Position Error
    1. Software detected an electronics failure of actuator switch contact.
  3. 051 - Steam Pressure Sensor
    1. Detected an out-of-range value for steam tank pressure sensor.
  4. 052 - Time Out Heater activation, Steam Tank
    1. Steam tank heating timeout has been reached even if the steam pressure is still under the setpoint.
  5. 058 - Steam Tank Overpressure
    1. Steam tank pressure has exceeded 1.85 bar.
  6. 059 - Steam Tank Refill Time Out
    1. Steam tank refill timeout has been reached even if the pump and solenoid valved are activated in order to refill the steam tank.
  7. 060 - Steam Tank Water Level Sensor Fault
  8. 151 - Brew Temp Sensor
    1. Machine software detected an out-of-range value for brew tank temperature sensor.
  9. 152 - Time Out Heater Activation, Brew Tank
  10. 159 - Brew Tank Fill Error
    1. Brew tank not filling properly due to missing feedback from the flowmeter.
  11. 166 - Missing Water During Extraction, Automatic Mode
    1. Automatic extraction not properly completed due to missing feedback from the flowmeter.
AlertSLAYER recommends all service be performed by an experienced SLAYER Espresso trained technician. For a technician reference near you, please contact SLAYER Support at (206)-284-7171 (#1 in Directory) or email support@slayerespresso.com.


Questions or concerns? Please contact support@slayerespresso.com
