 Parts Diagrams - 2025 - Updated Quarterly



IdeaSLAYER parts diagrams are for spare part identification and troubleshooting by experienced espresso technicians. Part numbers and prices are subject to change. Please contact SLAYER Support with a provided serial number for appropriate parts diagram.
Attached parts diagrams for the following production SLAYER models:
  1. Espresso Single
  2. Espresso V3
  3. Steam Single
  4. Steam EP
  5. Steam LP
Additional Information:
While a majority of parts listed in the attached diagrams are accurate. SLAYER acknowledges slight differences in finished goods against accompanying diagrams (exploded diagrams are updated quarterly). SLAYER Support is equipped to assist an experienced espresso technician identify compatible solutions.


  1. Legacy SLAYER parts diagrams may be found HERE.
  2. Price lists and parts orders, please contact SLAYER's Customer Service team at: 206 284 7171 (#3 in Directory) or orders@slayerespresso.com.
AlertSLAYER recommends all service be performed by an experienced SLAYER Espresso trained technician. For a technician reference near you, please contact SLAYER Support at (206)-284-7171 (#1 in Directory) or email support@slayerespresso.com.



    Questions or concerns? Please contact: support@slayerespresso.com
