Espresso Single Group Display Operation




Objective:
Navigate touch operations of LCD display.

Parts:
  1. 99004-60120 DISPLAY ASSEMBLY, HOME


Tools:
  1. Pad of your thumb.
Display Interaction:
Press intentionally (full contact surface using full pad of your thumb) against the center and lower half of the UP and DOWN triangle to toggle between menu selections while using the CENTER of circle to select and save. The interface below the displayed values features a LEFT and RIGHT swipe to navigate the menus.

Known Issue:
The down arrow on SLAYER Espresso Single Group's featuring a LCD display (machines manufactured and as a spare part after January 2020) indexes towards the bottom of the arrow. Access to the contact point is easier when you press down on the cup tray slightly.

Alert
Espresso Single Group's manufactured before January 2020 feature an OLED display. All displays purchased as a spare part through SLAYER's Customer Service team are the new, LCD, version and require factory configuration to remain compatible with older serial numbers. Please provide your serial number and date of manufacture (stamped on the data plate) to ensure the correct display configuration before purchase.


Questions or concerns? Please contact support@slayerespresso.com
