Single Group (Classic) Electronics Identification Diagram
Single Group Classic Electronics Diagram
Slayer Single Groups manufactured before January 2020.
1. Display Ribbon Cable | 7. Group Cap Magnet Switches |
2. Relay Harness | 8. Steam Tank Level Probe |
3. 24v DC Power | 9. Transducer |
4. Solenoids | 10. SSR Steam Relay |
5. Pump | 11. SSR Brew Relay |
6. Brew Tank RTD |
Questions or concern? Please contact: support@slayerespresso.com
