Hard Reset - Single Group

Hard Reset - Single Group


Hard Reset, Single Group

​


Step 1:
  1. Press circle to enter programming
  2. Scroll to Advanced Settings and circle to enter
  3. Scroll to menu option Save/Restore settings, press circle to enter
  4. Arrow up to Reset Factory Default
  5. Press circle, arrow to yes, press circle
  6. Arrow up to Reset Factory Tuned
  7. Press circle, arrow to yes, press circle
  8. Actuate group paddle to go to main screen.
  9. Unplug machine for 10 seconds
  10. Plug machine back in.

Step 2:

  1. Press circle to enter programming
  2. Scroll to Advanced Settings
  3. Select menu option Heater Control On/Off
  4. Turn on brew boiler
  5. Turn on steam boiler
  6. Actuate group paddle to go to main menu
  7. Machine should heat up in 20-30 min.

Step 3:

  1. Once machine is heated up, you'll need to set the pump pressure again.
  2. Press circle to enter programming
  3. Scroll to Brew Pump Pressure
  4. Press circle to bracket Pump Percentage
  5. Insert blind portafilter
  6. Turn on full brew
  7. Increase percentage until the bar pressure on the gauge reads 10 bar

Questions or concerns? Please contact: support@slayerespresso.com
