Resistance Specifications - Universal

Resistance Specifications - Universal


Resistance Specifications


Alert
SLAYER recommends all service be performed by an experienced SLAYER Espresso trained technician. For a technician reference near you, please contact SLAYER Support at (206)-284-7171 (#1 in Directory) or email support@slayerespresso.com.

Temperature Probe Resistance

Espresso V3
  1. Thermocouple Resistance
    1. Room Temp: 980-1000 Ohms
  2. 99003-20066 - Thermocouple Preheat (T1: orange band)
    1. 185F: 1500-1550 Ohms
  3. 99003-20065 - Thermocouple Steam (T2: red band)
    1. 250F: 1850-1900 Ohms
  4. 30000-20082 - RTD V3
    1. Room Temp: 100 Ohms
    2. 200F: 135 Ohms
Espresso Single Group
  1. 30004-20082 - RTD Single Group
    1. Room Temp: 500 Ohms
    2. 200F: 680 Ohms
Heating Element Resistance
Idea
Verify power configuration before identifying resistance!

Espresso Single Group:
  1. 30004-20130 - Brew Element, 600W 120V
    1. 21 Ohms
  2. 30000-20130 - Brew Element, 600W, 220V
    1. 24 Ohms
  3. 30004-20170 - Element, Dual, 2000W/400W, 110VAC
    1. Top - 25.5 Ohms
    2. Bottom - 19 Ohms
  4. 30004-20180 - Element, Dual, 1400W/600W, 220VAC
    1. Top - 36 Ohms
    2. Bottom - 83 Ohms
V3 & Steam Series - Two & Three Group:
  1. 30000-20130 - 600 Watt Brew Element
    1. 81 Ohms
  2. 30003-20110 - 1000 Watt Pre Heat Element
    1. 49 Ohms
  3. 30000-20090 - 3500 Watt Steam Element
    1. 14 Ohms
  4. 30000-20100 - 4500 Watt Steam Element
    1. 11 Ohms

Questions or concerns? Please contact: support@slayerespresso.com
