E015 Fill Error - Steam Single

E015 Fill Error - Steam Single



Troubleshooting <Fill Reservoir> - Steam Single


Known Issue:
SLAYER Steam Single reservoir indicator float is not indexing properly with the reed switch assembly. Resulting in an E015 Fill Error.



Symptoms:
  1. Machine does not recognize reservoir water level.
  2. Actuating brew circuit immediately prompts error.
  3. Steam tank autofill circuit does not activate.
    1. Steam tank autofill will not activate unless respective heater is turned on in Technical Menu.
  4. Machine does not heat.
Solution:
  1. Verify reservoir float is orientated in the correct position (illustration below).
    1. Flat side is facing towards internal reed switch.
    2. Darker beige circle (internal magnet) is UP.
    3. Rounded side is facing outwards.

  1. Float clip is pressed into position and secure.

  1. Water is filled to Max Level as indicated on the reservoir.

  1. Reservoir is fully inserted into tray.
  2. Reservoir o-ring is seated and locks into position.


Troubleshooting:
Alert
Do not attempt to bypass reed switch. This greatly increases the risk of running the machine dry.


Questions or concerns? Please contact support@slayerespresso.com
